Description

The Z3R-140 is the ultimate budget race bike from the Stomp stable. This bike boasts the upgraded SDG2 frame and the Detroit plastics, as well as the suspension from its podium-winning predecessor. The best 140 pit bike out there.The Z3R-140 still boasts the ‘exclusive to Stomp’ SR140C Z40 cam engine. Stomp buy in the YX140 and then fettle the engine with stiffened valve springs & a high lift race cam (known as the Z40 cam). The result is 2hp more than any other YX140 engine on the market.

ENGINE
Stomp Racing SR140C Z40 race cam

GEARBOX
Start-in-gear, all-up 4 speed gearbox

HORSEPOWER
14hp at rear wheel

CARB
26mm race carb with double foam filter

CASES
Aluminium shot blast finished cases with Stomp logo

COOLER
CNC oil cooler with braided steel hoses

FRAME
SDG2 heavy duty cradle frame for ultimate stiffness and control

SUBFRAME
Removable rear subframe & bolt on engine hangers

BASH PLATE
Alloy sump guard / bash plate

SWINGARM
410mm alloy swing arm

FORKS
SP 735mm cnc machined usd fully adjustable oil filled forks

CLAMPS
Drop forged black anodised triple clamps (yokes)

SHOCK
DNM nitrogen filled 290mm piggy back shock

WHEELS
14/12 sdg with steel rims for strength

RIM LOCK
In rear wheel

TYRES
Kenda

CYLINDERS AND CALIPERS
Improved and revised light-weight brake master

ROTORS
Vented light-weight rotors

FEATURES
Brake snake to protect the rear brake pedal

MUFFLER
Alloy oval exhaust muffler

RACE PIPE
Mandrill bent big bore 32mm OD race pipe

FEATURES
Features full length alloy heat shield for style and protection

BARS
Pro-taper style minibike bars

GRIPS
Renthal style soft rubber grips

LEVERS
Forged alloy clutch & brake levers

SIDE CASES
Stomp logo cnc machined engine side cases

CHAIN
420 KMC chain with engraved alloy/nylon chain guide

REAR SPROCKET
420 41t lightweight durable

FRONT SPROCKET
420 16t

GEAR SELECTOR
Fold back gear selector

FOOTPEGS
NEW upgraded PRO

FUEL TANK
NEW reinforced poly resin 5.5 ltr fuel tank with alloy cnc filler cap

SEAT
NEW revised firmer with Stomp logo

PLASTICS
NEW Detroit hi impact polypropylene

BOARD
Wrap around crf number board with front brake pipe tidy

GRAPHICS
New Stomp race graphics kit with Stomp race sponsor’s logos

SEAT HEIGHT
82cm

WEIGHT
71kg

WEIGHT LIMIT
15 stone
