Description

Back in 2007 Stomp were the first to take the legendary YX140 engine and squeeze it into a pit bike named “SuperStomp 140”. This absolute killer combination of an aftermarket frame and bonkers engine put Stomp firmly on the map. Ever since, Stomp fans and customers have been going crazy for their Pit Bikes, making Stomp a globally recognised brand. The Z3-140 continues this epic motorcycle brand legacy. It is still powered by that immense 4-stroke thumping single cylinder YX140. The engine is ‘exclusive to Stomp’ being the SR140C Z40 model producing 2hp more than any other YX140 engine on the market. If you look after the SR140C, it will prove a very reliable and affordable engine to run.
The chassis is a lightweight single backbone frame with cradle to keep the bikes mass down. This makes it faster and nimbler than many other brands focusing on MX looks at the cost of performance. The suspension is simple yet effective with plenty of travel. There’s even scope to upgrade the rear shock should you feel the need to start hitting some heavier jumps. The USD Forks and triple clamps complete the look while based on your personal preference the bike is available with two wheel options, 14/12 or 17/14 (big wheel).
The Z3-140 follows the trend for larger Pit Bikes, more space on the bike, yet still a lot of fun to throw around. Aggressive visual cues, clean lines and highly distinctive factory graphics complete a well-balanced looking bike that’s tasteful yet means business.

Warranty

6 months, parts only

Engine

YX140 with Z40 race cam, oil cooled

Valves

SOHC, 2 valve

Engine Displacement

140cc

Bore x Stoke

56 x 57mm

Compression Ratio

9.8:1

Fuel System

Carburettor 26mm Nibbi

Max Power

8.2 kw @ 8000 RPM

Max Torque

10.2 N·m @ 7500 RPM

Clutch

Wet, 5 disc

Ignition System

CDI

Starting System

Kick start

Transmission

Manual four speed with N-1-2-3-4

Final Drive

420 chain

Frame Design

Light-weight steel spine frame

Rear Subframe Design

CRF70 subframe

Swing Arm

Steel 430mm

Footpegs

Upgraded PRO Footpegs

Handlebar

Light weight steel

Front Suspension

USD 735mm (non-adjustable) forks

Rear Suspension

290mm piggy back (adjustable pre-load shock)

Front Rim

Steel rims with SDG hubs 14″

Rear Rim

Steel Rims With SDG Hubs 12″

Rim Lock

Rear

Front Tyres

60/100-14

Rear Tyres

80/100-12

Front Brake

Hydraulic brake 210 wavey disc

Rear Brake

Hydraulic brake 180 wavey disc

Wheelbase

1240mm

Ground Clearance

280mm

Seat Height

820mm

Dry Weight

71kg

Fuel Capacity

5.5 litres

Wheel Size

14/12

Packing Size

1560 x 380 x 735mm
